Point Leak Detection

WD-1 and WD-1-S are basic point water detectors featuring  silver-plated probes and microchip technology, a design that provides the highest level of water detection confidence. Power for the                  units may be from 12 to 24 VAC or VDC. For application flexibility,  form “C” relay points are provided for connection to MCT's GMP, MPR or similar monitoring equipment. The WD-1 and WD-1-S  are each housed in a height-adjustable, galvanized steel enclosure.

The WD-1 or WD-1-S may be utilized with any “contact closure” monitoring  panel or system. To accommodate virtually all installations, the “dry” contact points may be wired normally open or normally closed.      Once powered, relay contacts on the WD-1 remain in the same state until water reaches the sensing probes, closing the contact. The WD-1-S sensors are reverse acting and make contact as soon as power is supplied to the unit. The presence of water releases  the contact and the relay returns to a non-powered state.

Features:
Adjustable Probe Height  Wide Range of Operating Voltages Form "C" Relay Output for Alarms (1Amp/120Vac Rated) Silver  Red LED indicator light Encapsulated Electronics Fail-safe Circuitry (WD1-S Only)

Self Contained System
(No special monitor panel required) Design Flexibility, Simple Installation.

Specifications:

Model Number - WD1
Power - 12-24 Volts AC or DC @ 50MA Alarm Output - Form "C" Relay Contacts Indicator Light - Red LED
Contacts - (1Amp/120Vac Rated)
Environmental - 32-125F/0-95%Rh
Size - 5"L x 5"H x 3.25"D
Weight - 1.4 lbs.

 Model Number - WD1-S

Power - 12-24 Volts AC  or DC

@50MA Alarm Output -

Form "C"  Relay
   Indicator Light - Red LED
  Contacts - (1Amp/120Vac Rated      Reverse Acting)
Environmental - 32-125F/0-95%Rh
Size - 5"L x 5"H x 3.25"D
Weight - 1.4 lbs.

Some applications well suited for these packages include:

Water heater emergency drain pans.
Air conditioner condensation drain pans, Under-the-floor computer room monitoring and Flood drains.

The MCT WD1 –LP (Low Profile) series of Point Detectors featuring silver-plated probes and microchip technology for the highest level of water detection confidence. The design allows for a sturdier floor or pan mount as well as a lower
height profile for clearances.

All WD1-LP series detectors use the same proven and reliable

WD1 electronics.  All models can be operated from 12- 24 Volts AC or DC. Alarm signaling is provided  with one or two form “C” relay contacts, depending on the model ordered. Connect the WD1–LP to a MCT. MPR, GMP monitoring panel or a SCADA or BMS monitoring system to complete   the monitoring package. A height adjustable, galvanized steel enclosure is standard.

The WD1-LP models change the relay contact state, and lights the red LED on the cover when water is present at the sensing probes. The  WD1-LP model provide a single or dual set of dry relay contacts.  The WD1-LPS models include fail-safe circuitry  to signal an alarm condition for an internal malfunction  or loss of power to the sensor. The WD1-LPS  models incorporate a reverse acting set of relay contacts that are closed in a normal condition.

 Features:
Adjustable Probe Height
Lower Enclosure Height
Wide Range of Operating Voltages
Form "C" Relay Output for Alarms (1Amp/120Vac Rated)

Silver Sensing Probes
Red LED indicator light

Encapsulated Electronics
Fail-safe Circuitry (WD1-S Only)

Self Contained System
 (No special monitor panel required)
Design Flexibility
Simple Installation

 Specifications:
Model Number - WD1-LP

Power - 12-24 Volts AC or DC

@ 50MA Alarm Output -

Form "C"  Relay Contacts
Indicator Light - Red LED
Contacts - (1Amp/120Vac Rated)
Environmental - 32-125F/0-95%Rh
Size - 5"L x 5"H x 3.25"D
Weight - 2.0 lbs.

 Model Number - WD1-SLP

Power - 12-24 Volts AC or DC

@50MA  Alarm Output -

Form "C" Relay
Indicator Light - Red LED
Contacts - (1Amp/120Vac Rated   Reverse Acting)

Environmental - 32-125F/0-95%Rh
Size - 5"L x 5"H x 3.25"D
Weight - 2.0 lbs.

Some applications well   suited for these packages include:

Water heater emergency drain pans,

Air conditioner condensation drain pans, Under-the-floor computer room monitoring and Flood drains.

The MCT DD1 is a water point detector, featuring silver-plated probes and microchip technology for the highest level of water detection confidence. The DD1 can be operated from 12-25 Volts AC or DC. Alarm and control signaling is provided with form "C" relay contacts. The DD1 can be connected to any of MCT's monitoring systems to complete the monitoring package. The DD1 can also be used as a stand-alone controller for cooling or water flow shutdown.

Air Conditioning:

The DD1 relay contacts can be used to inhibit cooling when a high water level in a drain pan is detected. This will prevent water damage to the ceiling or flooring due to a clogged condensate drain.

Water Heaters:

The DD1 relay contacts can be used to close an electric solenoid when a water heater is dripping into an emergency drain pan. This will prevent serious water damage to the building should the emergency drain pan become clogged.

Mounting:

The DD1 sensing-probe, clips to the drain pan using a galvanized mounting bracket. The sensing probe is adjustable for maintaining the proper water level. The control module can be mounted on any flat, smooth surface using the mounting holes in the module feet.

Features:

Adjustable Probe Height

Remote Electronic Enclosure

Wide Range of Operating Voltages

Form "C" Relay Output for Alarms

(1Amp/120Vac Rated)

Silver Sensing Probes

Red LED indicator light

Encapsulated Electronics

Fail-safe Circuitry (DD1-S Only)

Self Contained System

(No special monitor panel required)

Design Flexibility

Simple Installation

Specifications:

Model Number - DD1

Power - 12-24 Volts AC or DC

@50MA Alarm Output -

Form "C" Relay Contacts

Indicator Light - Red LED

Contacts - (1Amp/120Vac Rated)

Environmental - 32-125F/0-95%Rh

Size - 5"L x 5"H x 3.25"D

Weight - 2.0 lbs.

Model Number - DD1-S

Power - 12-24 Volts AC or DC

@50MA Alarm Output -

Form "C" Relay

Indicator Light - Red LED

Contacts - (1Amp/120Vac Rated Reverse Acting)

Environmental - 32-125F/0-95%Rh

Size - 5"L x 5"H x 3.25"D

Weight - 2.0 lbs.

Some applications well suited for these packages include:

    Water heater emergency drain pans, Air conditioner condensation drain pans and

    Overflow Drain Pans.
